ZVA 25
1" HiFlo automatic nozzle for truck lanes and tanker deliveries, up to 140 l/min.
Overview
The ZVA 25 is the DN 25 size in Elaflex's ZVA nozzle family, meant for vehicles with large tanks where a car nozzle would keep the driver waiting. It passes up to 140 l/min at 0.5 to 3.5 bar. Where the pump pushes harder, the '5 bar' version carries the stronger main valve spring EF 362.6 VA and is rated for a maximum working pressure of 5 bar.
Inside, a patented venturi system shuts the nozzle off when the tank is full, a safety cut-out attitude valve reacts to the nozzle's position, and a check valve keeps the hose full between deliveries. The lever latch has three hold-open stages and a removable EB 280 pin. Fuel enters through a DN 25 swivel inlet with pressure flushing and an EK 372 strainer (25 mesh). Body and 31 mm spout are aluminium with a stainless steel tip, the guard is composite material and a soft black PVC cover protects the body. The complete nozzle weighs about 1.5 kg.
The part number tells you the guard and the hose thread. Guards 1, 2, 3, 4, 6, 6B and 8 suit different dispenser boots, and 'M' guards carry a block magnet for dispensers with reed contacts. The deadman type 'D' has no latch pin, so it cannot be left latched open. Spout ER 381.9 helps on narrow or awkward filler necks, and the LT type with polyurethane diaphragm parts works at ambient temperatures down to -55 °C. Apex supplies the ZVA 25 in Lebanon with matching SSB 25 breaks, sight glasses and genuine spare parts.
Key features
- DN 25 (1") HiFlo automatic nozzle, flow rate up to 140 l/min
- Working pressure 0.5 to 3.5 bar; max. 5 bar with main valve spring EF 362.6 VA
- For gasoline, diesel, fuel oil and petroleum; not for viscous oils or water
- Three-stage hold-open latch with removable latch pin EB 280
- DN 25 swivel inlet with pressure flushing and EK 372 strainer (25 mesh)
- Aluminium body, 31 mm aluminium spout with stainless steel tip, composite guard, approx. 1.5 kg
- Hose inlets G 1 AG, G 1 IG or 1" NPT IG
- 'M' guards with block magnet for reed contacts; deadman type 'D' without latch pin
- LT version for ambient temperatures down to -55 °C (fuel -40 °C to +40 °C)
- Optional SSB 25 safety swivel break with BS 21 sleeve, reusable or non-reusable 'NR'
Specifications
ZVA 25 technical data
| Part number | Guard style | Hose inlet |
|---|---|---|
| ZVA 25.1 | 1 | G 1 AG (1" BSP male) |
| ZVA 25.2 | 2 | G 1 AG (1" BSP male) |
| ZVA 25.3 | 3 | G 1 AG (1" BSP male) |
| ZVA 25.3M | 3M (block magnet) | G 1 AG (1" BSP male) |
| ZVA 25.4 | 4 | G 1 AG (1" BSP male) |
| ZVA 25.41 | 4 | G 1 IG (1" BSP female) |
| ZVA 25.45 | 4 | 1" NPT IG (1" NPT female) |
| ZVA 25.4M1 | 4M (block magnet) | G 1 IG (1" BSP female) |
| ZVA 25.61 | 6 | G 1 IG (1" BSP female) |
| ZVA 25.6B | 6B | G 1 AG (1" BSP male) |
| ZVA 25.8 | 8 | G 1 AG (1" BSP male) |
| ZVA 25.8DM rm | 8DMrm (block magnet) | G 1 AG (1" BSP male) |
Figures from the manufacturer's published documentation. Confirm the final configuration with Apex at quotation stage.
Questions
ZVA 25: common questions
- How fast does the ZVA 25 fill?
- Elaflex rates the ZVA 25 for up to 140 l/min. The flow you actually get depends on the dispenser pump, hose and fittings.
- Can the ZVA 25 be used on pumps above 3.5 bar?
- Yes, in its '5 bar' version. It is fitted with the stronger main valve spring EF 362.6 VA and is rated for a maximum working pressure of 5 bar.
- What does the 'M' in a part number such as ZVA 25.3M mean?
- It marks a guard with a block magnet, used on dispensers that detect the nozzle in its holder with reed contacts.
- Which safety break fits the ZVA 25?
- The SSB 25 safety swivel break, supplied with a BS 21 break sleeve. It screws into the nozzle with an M 42 x 1.5 thread and is rated for the same 140 l/min.
