TankSmart
Real-time fuel stock control, from probe to report.
TankSmart is Maser's wet-stock management system. Magnetostrictive probes in each tank measure product level, water and temperature, and the R_SMART TOP console and TankSmart software turn those readings into live stock figures, delivery records and alarms.
Volumes are temperature compensated to 15 °C, minimum levels are managed automatically and alerts go out by phone, SMS or e-mail so deliveries can be planned ahead. The system connects to the station management software and to major ERP systems. Apex supplies, installs and supports TankSmart in Lebanon.
Key features
- Magnetostrictive probes for product level, water and temperature
- Automatic sludge and water detection
- Temperature compensation to 15 °C
- Automatic minimum-level management and blocking of contaminated fuel dispensing
- Pre-emptive alerts by phone, SMS or e-mail
- No practical limit on the number of tanks; all tank types supported
- R_SMART TOP console: 7" touch screen, up to 16 tanks, static and dynamic leak detection, tank auto-calibration and automatic reconciliation
- Optional MS_Density module for continuous density measurement on the same probe
- Remote hardware diagnostics and secure link to head-office ERP
Product lines
What this range covers
MS_EXIA Probe
Stainless-steel magnetostrictive level probe for standard tanks, measuring length up to 6 m.
MS_EXIA FLEX Probe
Flexible probe for large tanks with measuring length up to 25 m, folds for compact transport.
R_SMART TOP Console
Wall-mounted gauge console with 7" touch screen for up to 16 tanks.
MS_Density Module
Density float that mounts on the MS_EXIA probe for product quality control.
Specifications
Models and technical data
| MS_EXIA Probe | MS_EXIA FLEX Probe | |
|---|---|---|
| Measuring length | Up to 6 m | Up to 25 m |
| Product level accuracy | ± 0.25 mm | ± 1 mm |
| Product level repeatability | ± 0.05 mm | ± 0.2 mm |
| Water level accuracy | ± 0.25 mm | ± 1 mm |
| Temperature range | -40 °C to +80 °C | -40 °C to +80 °C |
| Temperature accuracy | ± 0.2 °C (-20 °C to +70 °C) | ± 0.2 °C (-20 °C to +70 °C) |
| Product float | Ø 45 mm, AISI 316 L | Ø 98 mm |
| Head protection | IP68 | IP68 |
| Approvals | ATEX, PESO, OIML R85 | ATEX, OIML R85 |
Figures from the manufacturer's published documentation. Confirm the final configuration with Apex at quotation stage.
Request a Quotation
Get a quotation for TankSmart.
Tell us the quantities and the site. Apex prepares every quotation for the project, then supplies, installs and services the equipment in Lebanon.
